350kg/H PS Single Shaft Shredder Grinder Machine

Name: 350kgH PS Single Shaft Shredder Grinder Machine
Brand: BEISU
Price: 14 USD

Buy cheap 350kg/H PS Single Shaft Shredder Grinder Machine product

Place of Origin : CN;JIA

Brand Name : BEISU

Certification : CE,ISO

Supply Ability : 200 Set/Sets per Year

Packaging Details : Film packing or wood package as customer requirements

MOQ : >=1 Sets

Price : $14,000.00

Condition : New

Plastic Type : PS

Machine Type : Plastic Shredder

Max.Production Capacity (kg/h) : 350

Production Capacity (kg/h) : 300 - 350 kg/h

Use : Waste Plastic Crusher

Shaft Design : Single

Voltage : 220V/380V/415V/440V

Dimension(L*W*H) : 3000mm*1500mm*2200mm

Power (kW) : 37

Weight (T) : 1500

Key Selling Points : Automatic

Raw material : PE pipes/PVC pipes/Wood/Pallets/Plastic containers

Motor power : 37Kw and 15Kw

Material blade : SKD-11 or Stainless steel or Tungsten steel

Blade type : V or W

Rotary blade : 26

Fixed blade : 2PCS

Bearing brand : NSK or SKF or Wafandian

OIL filling system : Oil pump

Contactor brand : Internationally renowned brand

PLC : Internationally renowned brand

Port : SHANGHAI or NINGBO PORT

Model Number : BS-600

Contact Now

350kg/H PS Single Shaft Shredder Grinder Machine

Plastic film, thick wall pipes plastic crusher Line Single Shaft Shredder Equipment:

Compact Single shaft shredder combined with great power.
Variable adjustable screens to determine the size of the chips
Hydraulic feed to ensure constant material flow to the rotor
V-belt drive gear reduction through spur gearing
Hydraulic unit and hydraulic cylinder suspended by cardanic joints
in small or medium-sized companies which attach great importance to an optimum cost -benefit ratio.

Applications of Single Shaft Shredder:

To process plastic material: thick wall diameter plastic pipes, plastic film, waste injection products,

plastic bottles, bags, and so on.
strong crushing shredders
contrarotation with the structure of close-lined rotary knives in double direction.

Features of Single Shaft Shredder:

1.The shredder rotation of low speed 60~100rpm which could working steady and gentle even when process really rough pieces.
2.High quality gearbox used on driving system.
3.High thickness steel used on sturcture and frame for enhancing the stability of equipment.

4.Long life knives used. The unique designed square knives are bolted on the strong rotor and the jagged teeth knife installed in
front side of the cut chamber stationary knife which are the key parts for cut off all the feeded materials.Square knives has four edges could be change before replacement.

5.The PLC controlled hydraulic pusher forces material to the rotor automatically.

6.Low Power consumption

7.The screen filter sizes ranges for varies material particle size control.

8.Easy for operation maintainence

Model	Power (KW)	Hydraulic power (KW)	Rotor diameter (mm)	Capacity approx. (kg/h)
BS-600	18.5/22	1.5	300	300-500
BS-800	37/45	2.2	400	500-800
BS-1000	55/75	2.2	400	800-1000
BS-1200	75/90	5.5	450	1000-1500
BS-1500	90/110	5.5	500	1500-2000
